Position Punching Machine inline connectable with bookbinding lines stable cam punching cardboard applicable

Name: Position Punching Machine inline connectable with bookbinding lines stable cam punching cardboard applicable
Brand: HXCP
Price: 24300 USD

China Position Punching Machine inline connectable with bookbinding lines stable cam punching cardboard applicable wholesale

Product Size : A3/A4/A5

Speed : 100-130times/min

Weight : 1300kg

Packaging Details : Stretch Film with Wooden Case

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Power Supply : AC380V

Model Number : HX350DK

Product Thickness : 0.5-4mm

MOQ : 1 set

Certification : CE

Dimensions : 2580×1200×1200mm(L×W×H)

Supply Ability : 10 sets/month

Brand Name : HXCP

Price : USD 24300 per set

Place of Origin : China

Power : 2.2kw

Delivery Time : 30 work days

Contact Now

Nowadays printing and bookbinding factories demand flexible, efficient punching equipment to handle diversified stationery and paper products. The Automatic Access Punching Machine is engineered to fulfill various positioning punching needs across multiple materials, standing as a practical core device for post-press production.

Position Punching Machine inline connectable with bookbinding lines stable cam punching cardboard applicable

This punching unit boasts outstanding material compatibility. It perfectly processes notebooks, diaries, bound books, leaflets, folded signatures, calendars, cardboard and PP plates, covering most common finished goods in modern printing workshops. Its wide application range enables manufacturers to centralize different punching tasks on one single machine and simplify equipment allocation.

For flexible production layout, the machine features excellent expandability. It can be seamlessly linked with folding machines and complete bookbinding production lines for inline continuous processing. Users also have the option to install a flat pile feeder to realize fully automatic sheet feeding, freely switching between standalone offline production and assembly line linked production according to order plans.

Product Size
A3/A4/A5

Product Thickness
0.5-4mm

Speed
100-130times/min

Dimensions
2580×1200×1200mm(L×W×H)

Power Supply
AC380V

Power
2.2kw

Weight
1300kg

Powered by a reliable cam-driven punching mechanism, the equipment runs steadily during long-duration batch processing. The cam structure delivers consistent punching force and accurate hole positioning, effectively avoiding irregular hole size or offset holes that frequently appear on low-grade punching devices, securing uniform finished quality for every product batch.

Equipped with automatic stacking delivery structure, the machine greatly cuts down manual workload. Neatly stacked finished sheets after punching only require collection by a single operator, drastically reducing labor input and lowering factory daily operating costs compared with traditional manual and semi-automatic punching equipment.

Thanks to flexible configuration options, stable mechanical performance and labor-saving design, this automatic punching machine suits small customized orders and large-scale mass production alike. It is an economical upgrade choice for printing plants, stationery manufacturers and bookbinding workshops aiming to improve punching efficiency and finished product standardization.
